Wire Management products:improved flex and strain relief for panels and enclosure applications.These ON-the Shelf products give the OEM user a wide range of choices with 1000's of parts ready to ship. All parts are RoHS |
|||||
|
CUSTOM DESIGNS available by special order |
|||||
| Print Page | |||||
|
ROUND |
|||||
|
|||||
|
|||||
| STYLE | HOLE DIA. | SLOT WIDTH | SLOT SIZE | FLANGE SIZE | COLOR | STYLE | HOLE DIA. | SLOT WIDTH | SLOT SIZE | FLANGE SIZE | COLOR |
| 1461040 | - | .100 | - | .062 | - | .205 | - | .330 | - | 0 | 1461040 | - | .100 | - | .062 | - | .205 X.205 | - | .330 | - | 0 | |
| 1461040 | - | .125 | - | .062 | - | .205 | - | .330 | - | 0 | 1461040 | - | .125 | - | .062 | - | .205 X.205 | - | .330 | - | 0 | |
| 1461040 | - | .150 | - | .062 | - | .310 | - | .440 | - | 0 | 1461040 | - | .150 | - | .062 | - | .310 X.310 | - | .440 | - | 0 | |
| 1461040 | - | .175 | - | .062 | - | .310 | - | .440 | - | 0 | 1461040 | - | .175 | - | .062 | - | .310 X.310 | - | .440 | - | 0 | |
| 1461040 | - | .200 | - | .062 | - | .310 | - | .440 | - | 0 | 1461040 | - | .200 | - | .062 | - | .310 X.310 | - | .440 | - | 0 | |
| 1461040 | - | .225 | - | .062 | - | .310 | - | .440 | - | 0 | 1461040 | - | .225 | - | .062 | - | .310 X.310 | - | .440 | - | 0 | |
| 1461040 | - | .250 | - | .062 | - | .310 | - | .440 | - | 0 | 1461040 | - | .250 | - | .062 | - | 310 X.310 | - | .440 | - | 0 | |
| 1461040 | - | .275 | - | .062 | - | .460 | - | .651 | - | 0 | 1461040 | - | .275 | - | .062 | - | .460 X.460 | - | .651 | - | 0 | |
| 1461040 | - | .300 | - | .062 | - | .460 | - | .651 | - | 0 | 1461040 | - | .300 | - | .062 | - | .460 X.460 | - | .651 | - | 0 | |
| 1461040 | - | .350 | - | .062 | - | .460 | - | .651 | - | 0 | 1461040 | - | .350 | - | .062 | - | .460 X.460 | - | .651 | - | 0 | |
| 1461040 | - | .400 | - | .062 | - | .460 | - | .651 | - | 0 | 1461040 | - | .400 | - | .062 | - | .460 X.460 | - | .651 | - | 0 | |
| 1461040 | - | .450 | - | .062 | - | .610 | - | .863 | - | 0 | 1461040 | - | .450 | - | .062 | - | .610 X.610 | - | .863 | - | 0 | |
| 1461040 | - | .500 | - | .062 | - | .610 | - | .863 | - | 0 | 1461040 | - | .500 | - | .062 | - | .610 X.610 | - | .863 | - | 0 | |
| 1461040 | - | .550 | - | .062 | - | .610 | - | .863 | - | 0 | 1461040 | - | .550 | - | .062 | - | .610 X.610 | - | .863 | - | 0 | |
| 1461040 | - | .600 | - | .062 | - | .810 | - | 1.150 | - | 0 | 1461040 | - | .600 | - | .062 | - | .810 X.810 | - | 1.150 | - | 0 |
| STYLE | HOLE DIA. | SLOT WIDTH | SLOT SIZE | FLANGE SIZE | COLOR | STYLE | HOLE DIA. | SLOT WIDTH | SLOT SIZE | FLANGE SIZE | COLOR |
| 1461040 | - | .100 | - | .125 | - | .205 | - | .330 | - | 0 | 1461040 | - | .100 | - | .125 | - | .205 X.205 | - | .330 | - | 0 | |
| 1461040 | - | .125 | - | .125 | - | .205 | - | .330 | - | 0 | 1461040 | - | .125 | - | .125 | - | .205 X.205 | - | .330 | - | 0 | |
| 1461040 | - | .150 | - | .125 | - | .310 | - |
